型号参数表
| 序号 | 型号 | 尺寸（mm） | 功率（W） | 建议选配控制器 | ||
| W/G/B | R | |||||
| 1 | 侧面导光光源 | HL-FL5050K | 发光区50×50 | 8.5 | 4.5 | HL-APC2424P HL-APC2460P HL-MDPC2480 HL-DPC2465D |
| 2 | HL-FL7070K | 发光区70×70 | 9.0 | 9.0 | ||
| 3 | HL-FL100100K | 发光区100×100 | 13.0 | 9.0 | ||
| 4 | HL-FL150150K | 发光区150×150 | 17.5 | 13.0 | ||
| 5 | HL-FL200200K | 发光区200×200 | 25.0 | 17.5 | ||
| 6 | HL-FL250150K | 发光区 250×150 | 26.0 | 22.0 | ||
| 7 | HL-FL250200K | 发光区250×200 | 26.0 | 22.0 | ||
| 8 | HL-FL300200K | 发光区300×200 | 31.0 | 22.0 | ||
| 9 | HL-FL300250K | 发光区300×250 | 31.0 | 22.0 | ||
| 10 | HL-FL300300K | 发光区300×300 | 31.0 | 22.0 | ||
| 11 | HL-FL400300K | 发光区400×300 | 43.5 | 35.0 | ||
| 12 | HL-FL600450K | 发光区600×450 | 61.0 | 52.0 | ||
| 13 | 开孔侧面导光光源 | HL-FL100100K-K35 | 发光区 100×100 开孔35 | 12.5 | 12.5 | |
| 14 | HL-FL200200K-K50 | 发光区 200×200 开孔50 | 20.5 | 19.5 | ||
| 15 | HL-FL250120K-K50 | 发光区 250×120 开孔50 | 26.0 | 22.0 | ||
| 16 | HL-FL250150K-K50 | 发光区250×150 开孔50 | 26.0 | 22.0 | ||
| 17 | HL-FL250250K-K50 | 发光区250×250 开孔50 | 26.0 | 22.0 | ||
| 18 | HL-FL300200K-K50 | 发光区300×200 开孔50 | 31.0 | 22.0 | ||
| 19 | HL-FL300300K-K50 | 发光区300×300 开孔50 | 31.0 | 22.0 | ||
| 20 | HL-FL400200K-K40 | 发光区400×200 开孔40 | 43.5 | 35.0 | ||
| 21 | HL-FL400300K-K50 | 发光区400×300 开孔50 | 43.5 | 35.0 | ||
| 22 | HL-FL500400K-K70 | 发光区500×400 开孔70 | 52.0 | 43.0 | ||
| 23 | HL-FL600450K-K50 | 发光区600×450 开孔50 | 57.5 | 50.0 | ||
| 24 | HL-FL800600K-K50 | 发光区800×600 开孔50 | 74.5 | 65.0 | ||
| 25 | HL-FL900618K-K50 | 发光区900×618 开孔50 | 51.0 | 45.0 | ||
| 26 | HL-FL1568668K-K50 | 发光区1568×668 开孔50 | 151.0 | 120.0 | HL-DPC24200 | |
